OTS-mux/Demux

2026-07-10 15:17 Views 25 In Stock

OTSLink P/N: OTS-mux/Demux SKU: OTS-mux/Demux Unit: pcs

DWDM Mux/Demux: 48/96 channels, <6dB insertion loss, 1U rack or DCI 1/2-slot blade, GR-1221 compliant.

Request Quote

Specifications

Function: multiplex / demultiplex 48-96 DWDM optical signals; smooth online upgrade to 96 channels; low insertion loss, high channel isolation, reliable and stable, GR-1221 compliant.

Form factor: 1U 19-inch rack-mount device, or DCI-chassis 1/2-slot blade.

Channels: 48 lambda @100GHz, 96 lambda @50GHz (191.3THz - 196.0THz).

Insertion loss: <6dB.

Supervision: MUX-side and DEMUX-side MON monitoring ports.

Management: RJ45 NMS port, reads device SN/PN, reports presence/absence, supports dormant-resource management.

Application Scenario

Key Features

Mux/Demux capacity: 48-channel (100GHz) / 96-channel (50GHz) DWDM, 191.3-196.0THz
Smooth expansion: online DWDM system upgrade, easy maintenance
Optical performance: insertion loss <6dB, high channel isolation, GR-1221 compliant
Monitoring: MON port + RJ45 NMS, reads SN/PN, reports presence, dormant-resource management
Dual form factor: 1U 19-inch rack or DCI-chassis 1/2-slot blade
