Specifications
Function: automated optical alignment and assembly (high throughput, multi-parameter optimization, high precision / repeatability, operator-independent); optional integrated PLC + OCM for per-channel output power control; reconfigurable and dynamically tunable with strong node-reconfiguration capability.
Slots: 1/2 slot.
Ports: MON optical supervision port, OTDR diagnostic port.
Operating wavelength: 1528.773 - 1566.73nm.
Extinction ratio: >=25dB.
Port isolation: >25dB.
Channel insertion-loss variance: <=2.5dB.
Reconfiguration time: <=3s.
MON split ratio: 16-23dB.
