OTS-400G-MXP-DD

Specifications

Capacity: 4x100G bidirectional

Tunable wavelength (DWDM): 1529.16nm - 1567.14nm

Modulation: DP-QPSK@100G; DP-16QAM@200G; DP-8QAM@200G; DP-QPSK@200G; DP-8QAM@300G; DP-16QAM@400G

Line-side protocol: OpenROADM / OpenZR+ / SCFEC

CD tolerance: +/-40000ps/nm @100G

OSNR tolerance: <14dB@100G QPSK; <17.5dB@200G DP-8QAM; <19.5dB@200G DP-16QAM; <16dB@200G DP-QPSK; <24dB@400G DP-16QAM

Service access: 100GE, 100GE-KR4, OTU4

Dimensions: 85.7 (W) x 40.3 (H) x 209.86 (D) mm

Operating temp: -5C ~ 45C; Storage temp: -40C ~ 80C; Relative humidity: 5%~95% non-condensing

Safety / EMC: FCC, UL, CE, TUV, CSA; Power: <80W
